VFU-Vacuum Filter
- Manufacturer: CHELIC
- Model: VFU-Vacuum Filter
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Normal standard:individual package with labels and outside is normal brown box. |
| Delivery Time: | 7-10 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000PCS per month |
Support 24/7
+84 969. 023. 899 - (+84 707. 583. 779)
- Product details
- CATALOGUE
- 2D/3D Drawings
Description
VFU-Vacuum Filter
Features of Vacuum Filter：
1.Negative pressure filtration:To filtering and removing dust and other foreign matter from the air. The density of the impurities is 40μm and the connection port
2.Easy to replace: When the filter element is blocked and the flow is affected, the cup body is easy to disassemble and easy to replace.
| Model | VFU01-04、VFU01-06、VFU02-06、VFU02-08、VFU03-08、VFU03-10 |
| Port size ( IN Side, OUT Side ) L/min(ANR) | VFU01-04:4 FU01-06、VFU02-06:6 VFU02-08、VFU03-08:8 VFU03-10:10 |
| Flow | VFU01-04:10 VFU01-06:20 VFU02-06:30 VFU02-08:50 VFU03-08、VFU03-10:75 |
| Fluid | Air |
| Nominal filtration rating(µm) | 30 |
| Proof pressure(MPa(kPa)) | 0.5(500) |
| Pressure range(MPa(kPa)) | -0.1~0(-100~0) |
| Ambient and fluid temperature(°C) | 0 ~ 60(No freezing status) |
| Element differential pressure resistance(MPa(kPa)) | 0.15 (150) |
| Applicable piping tube | Nylon、Soft nylon |
