AIR15-950/3
- Manufacturer: Peitian Robot
- Model: Desktop Series AIR15-950/3
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Normal standard:individual package with labels and outside is normal brown box. |
| Delivery Time: | 25-30 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000PCS per month |
Support 24/7
+84 969. 023. 899 - (+84 707. 583. 779)
- Product details
- DOWNLOAD
Description
Desktop Series AIR15-950/3
High protection level, High speed, High precision, High stability
Applicable industries: Computer, Communication & Consumer Electronics, Metal processing, Food processing, Pharmaceutical manufacturing…
| 型号 Type | AIR15-950/3 | |
|---|---|---|
| 轴数 Axes | 4 | |
| 负载 Payload | 15kg | |
| 机器人本体 Manipulator |
重量 Weight | 62kg |
| 最大运动范围 Reach | 947mm | |
| 定位精度 Positioning accuracy |
位置重复定位精度 Position repeatability |
±0.025mm |
| IP等级 Ingress Protection |
IP67 | |
| 安装方式 Mounting |
吊装 Ceiling |
|
| 运动范围 Working range |
轴1① Axis 1 | – |
| 轴2 Axis 2 | -95°/+135° | |
| 轴3 Axis 3 | -120°/+156° | |
| 轴4 Axis 4 | – | |
| 轴5 Axis 5 | -135°/+135° | |
| 轴6 Axis 6 | -360°/+360° | |
| 运动速度 Rotation rate |
轴1 Axis 1 | – |
| 轴2 Axis 2 | 320°/s | |
| 轴3 Axis 3 | 350°/s | |
| 轴4 Axis 4 | – | |
| 轴5 Axis 5 | 565°/s | |
| 轴6 Axis 6 | 405°/s | |
| 适用控制柜 Controllers |
inCube20/inCube20T | |
| ①若去除机械限位，运动范围可达 -180°/+180°。 If the mechanical limit is removed, the working range can reach -180° /+180°. | ||
| Type | Reach (mm) | Payload (kg) | Ingress Protection | Axes | Mounting |
| AIR4-560 | 560 | 4 | IP67 | 6 | Floor / Ceiling / Wall |
| AIR4-560-HW | 560 | 4 | IP65 | 6 | Floor / Ceiling / Wall |
| AIR7-920 | 920 | 7 | IP67 | 6 | Floor / Ceiling / Wall |
| AIR8-710 | 710 | 8 | IP67 | 6 | Floor / Ceiling / Wall |
| AIR10-1210 | 1211 | 10 | IP67 | 6 | Floor / Ceiling / Wall |
| AIR15-950 | 947 | 15 | IP67 | 6 | Floor / Ceiling / Wall |
| AIR15-950-HI | 947 | 15 | IP67 | 6 | Floor / Ceiling / Wall |
| AIR15-950/3 | 947 | 15 | IP67 | 6 | Ceiling |
| AIR15-950/4-HI | 947 | 15 | IP67 | 6 | Ceiling |
