RMF-Rotary Table
- Manufacturer: CHELIC
- Model: RMF-Rotary Table
| Minimum Order Quantity: | 30pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Normal standard:individual package with labels and outside is normal brown box. |
| Delivery Time: | 10-30 work days |
| Payment Terms: | T/T |
| Supply Ability: | 10,000PCS per month |
Support 24/7
+84 969. 023. 899 - (+84 707. 583. 779)
- Product details
- CATALOGUE
- 2D/3D Drawing
Description
RMF-Rotary Table
Features of Rotary Table：
- With radial bearings: The rotary platform is supported by two sets of radial bearings, which can be directly installed. Multiple styles: A total of 90°, 180° angles are available. Its angle can be adjusted slightly with the adjustment screw. Automated control: Optional sensor fixed seat with sensor for control.
| Model | RMF10/RMF15/RMF20/RMF30/RMF40/RMF50 |
| Action | Double acting |
| Fluid | Air |
| Torque force(N･m) | RMF10:0.14 RMF15:0.38 RMF20:0.78 RMF30:1.8 RMF40:3.8 RMF50:5 |
| Rotation angle | 90°、180° |
| Pressure range(kgf/cm² (kPa)) | RMF10:2~7(200~700) RMF15/RMF20/RMF30/RMF40/RMF50 |
| Port size | RMF10/RMF15/RMF20/RMF30/RMF40:M5x0.8 RMF50:PT1/8 |
| Ambient and fluid temperature(°C) | 5∼60 |
| Allowable kinetic energy(J) | RMF10:0.05 RMF15:0.013 RMF20:0.032 RMF30:0.056 RMF40:0.1 RMF50:0.2 |
