SRM 5 Ports Solenoid Valve
- Manufacturer: CHELIC
- Model: SRM Solenoid Valve
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Normal standard:individual package with labels and outside is normal brown box. |
| Delivery Time: | 7-10 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000PCS per month |
Support 24/7
+84 969. 023. 899 - (+84 707. 583. 779)
- Product details
- CATALOGUE
Description
SRM-Remote Control/Base Mounted Solenoid Valve
Features of Remote Control/Base Mounted Solenoid Valve：
1. Various types: Capable with SRB series solenoid valve.
2. Fitting port selection: The port size can be adjusted as required.
3. Simple wiring: D-type Fitting port, easy and fast for wiring.
4. Pressure monitoring: The pressure of air source can be display with a set of switch to output.
5. Modulable and maximum to 10 stations.
| Model | SRM 300 SRM 500 |
| Fluid | Air |
| Pressure range kgf/cm² (kPa) | 1.5~7 ( 150 ~700 ) |
| Ambientand fluid temperature °C | 0 ~ 50 |
| Pilot type | Air operated |
| Number of positions | 4/2-position; 4/3-position |
| Type of actuation | Normally closed |
| Orifice mm²(CV) | SRM 300:3.6 (0.2) SRM 500:10.8 (0.6) |
| Manual override | Push-turn and lock |
| Port size A,B | SRM 300:Ø4、Ø6 SRM 500:Ø6、Ø8 |
| Port size P,R | SRM 300:Ø6、Ø8 SRM 500:Ø8、Ø10 |
| Lubrication | Lubrication free type |
| Voltage DC | 24 V±10% |
| Manifold quantity | 2 ~ 10 M |
| Cable type | D-Sub(25pin) |
